| Languages | Current version | ||
|---|---|---|---|
| Quick Guide | V01 01/10 | ||
| Labelling template | 02 08/07 | ||
| Instructions a/b Switching Module | V03 10/2020 | ||
| Operating instructions | V09 10/2020 | ||
| Statements of conformity | V09 10/2022 |
Note about qualified electrician complemented.
Note about door bell transformer complemented. Note about inflammable materials deleted.
Operating voltage: Values changed
Contact load capacity: Values changed
The COMpact 3000 analog/ISDN/VoIP PBXs don't feature an interface for FTZ-standard doorphones.
However, you can use analog doorphones such as our TFS-Dialog 20x/30x/universal plus. In addition, you can use the TSA - a / b use this converter can convert different doorphone to a / b port .
Recommended parameter settings for Auerswald door intercom systems
| TFS-Universal plus / a/b TFS-Dialog 300 / 400 | TFS-Dialog 200 | |||
| Sensitivity | Volume | Sensitivity | Volume | |
| Parameters | 50 | 57 | 50 | 57 |
| Default value | 3 | 2 | 3 | 2 |
| Auerswald | ||||
| COMander Basic.2 COMmander Business | 3 | 2 | 3 | 3 |
| COMpact 2206 USB COMpact 4410 USB COMpact 4406 DSL | 3 | 0 | 3 | 0 |
| COMpact 2104.2 USB COMpact 2204 USB | 3 | 1 | 3 | 1 |
| ETS-1006 FAX | 1 | 2 | 1 | 2 |
| ETS-2106 I Rev.2 ETS-2204 I ETS-4308 I | 5 | 1 | 5 | 1 |
| Agfeo | ||||
| Agfeo AS 40 | 5 | 3 | 5 | 3 |
| AVM | ||||
| Fritz Box | 3 | 2 | 9 | 1 |
| Fritz Box Fon WLAN 7050 | 3 | 2 | 6 | 6 |
| FEC/Elmeg | ||||
| Elmeg ICT 46 | 5 | 3 | 5 | 3 |
| Panasonic | ||||
| Panasonic KX-TDA15 | 1 | 0 | 3 | 1 |
Note: The installation location, the internal room acoustics and the number of connected a/b switching modules may influence the specified values. The parameter values may deviate from the recommended values.
